Shark-500 Top Suction Sheet-fed Quality Inspection Machine
Model: FS-SHARK-500-TS
Product Details
Place of OriginChina
Brand NameFOCUSIGHT
CertificationISO9001/CE
Model NumberFS-SHARK-500-TS
Maximum Inspection Size500 × 400 mm (Horizontal × Vertical)
Minimum Inspection Size100 × 100 mm (Horizontal × Vertical)
Paper Thickness180 ～ 350 g/㎡
Maximum Inspection Speed180 m/min
Imaging Precision0.11 × 0.1 mm (Customizable upon request)
Machine Dimensions6630mm (L) × 2820mm (W) × 1950mm (H)
Feeder TypeTwo Top Suction Feeders / One Top Suction + One Friction Feeder
Transmission ModeFully Suction Platform
Front Cameras1–3 High-Speed Cameras
Printing Defect Camera4K resolution, 36K horizontal frequency 3CCD German color high-speed camera
Laminating / Embossing Camera8K resolution, 36K horizontal frequency TDI CCD panchromatic high-speed camera
Silk Screen / Gloss Oil Camera8K resolution, 36K horizontal frequency TDI CCD panchromatic high-speed camera
Reverse Side Camera1 high-speed CCD camera (optional)
Software ModuleColor separation module (optional)
Payment & Shipping Terms
Minimum Order Quantity1 Unit
PriceNegotiable
Packaging DetailsPlywood Case
Delivery Time60 Days
Payment TermsL / C , T / T
Supply Ability20 Per Month
Detail Information
| Spec | Value | Spec | Value |
|---|---|---|---|
| Place of Origin | China | Brand Name | FOCUSIGHT |
| Certification | ISO9001/CE | Model Number | FS-SHARK-500-TS |
| Maximum Inspection Size | 500 × 400 mm (Horizontal × Vertical) | Minimum Inspection Size | 100 × 100 mm (Horizontal × Vertical) |
| Paper Thickness | 180 ～ 350 g/㎡ | Maximum Inspection Speed | 180 m/min |
| Imaging Precision | 0.11 × 0.1 mm (Customizable upon request) | Machine Dimensions | 6630mm (L) × 2820mm (W) × 1950mm (H) |
| Feeder Type | Two Top Suction Feeders / One Top Suction + One Friction Feeder | Transmission Mode | Fully Suction Platform |
| Front Cameras | 1–3 High-Speed Cameras | Printing Defect Camera | 4K resolution, 36K horizontal frequency 3CCD German color high-speed camera |
| Laminating / Embossing Camera | 8K resolution, 36K horizontal frequency TDI CCD panchromatic high-speed camera | Silk Screen / Gloss Oil Camera | 8K resolution, 36K horizontal frequency TDI CCD panchromatic high-speed camera |
| Reverse Side Camera | 1 high-speed CCD camera (optional) | Software Module | Color separation module (optional) |
Product Description
Focusight Shark-500 Top Suction Sheet-fed Inspection System is specially designed for scratch-sensitive folding cartons such as cosmetics, electronic, and Metpet packaging. Featuring a dual top-suction feeding platform, high-speed 4K/8K German CCD cameras, and quick 2-minute job switchover.
Key Features
- Scratch Proof: Adopt top suction feeding method, completely avoids scratches between knife and paper
- Quickly switch: Feeder unit with top suction method is very easy to adjust; transportation requires no adjustment due to full suction platform
- Fast Changeover: 2 minutes to complete machine adjustment for a new product
- Ideal for Sensitive Substrates: Specially engineered for easily scratched products such as cosmetics, electronics, and Metpet products with PVC, polished, or varnished surfaces
- Irregular Cartons Support: Especially suitable for frequently switched jobs and irregularly shaped products
- High-Precision 4K/8K Inspection: German 3CCD color camera + TDI panchromatic cameras detect print, foiling, lamination, and UV defects accurately
- Application Industry: Folding cartons, cosmetics packaging, electronics, luxury goods, and pharmaceuticals
